Product Description
The core design of the LD customized DC5025 blower is a small-sized, high-pressure, side-outflow micro centrifugal blower, suitable for equipment with compact spaces and high duct resistance. It is made of environmentally friendly and fire-resistant PBT material and is widely used in air purifiers, humidifiers, and other small appliances, as well as industrial control machines and small servers.
DC50*50*25mm;
Voltage:5V/12V/24V;
Current:0.08~0.35A;
Bearing:Sleeve /Ball Bearing;
Materials:PBT;
Speed:3000~5000RPM;
Power:0.8~3W;
CFM:3~5.3CFM;
Noise:34~47db;
Weight:30g;
DC50*50*25Blower Design Parameters
Motor Protection: RP/SS/AS/CL
Signal Output:FG/RD/LD
Speed Contorl Method：PWM/TP/VC/RC/CS
LDDC5025 Blower Design Application Product Types:
DC5025 Blower Wide Applications
Air purifier, small humidifier, aroma diffuser
Projector, laser printer, copier
Industrial control computers, embedded devices, small servers
Medical equipment (nebulizers, beauty devices, portable testing devices)
3D Printer (Nozzle Cooling, Air Duct Circulation)
Power supply, inverter, charging station, UPS
Smart Home (Smart Toilet, Water Dispenser, Small Fresh Air System)
