Product Description
LDECΦ310100 EC110/230V Fan
Wind turbine diameter: 310 mm;
Fan thickness (depth): 100 mm;
Number of blades: 6;
Rotation direction: Counterclockwise when viewed from the lead wire;
Protection level: IP42;
Bearings: Ball bearings;
Insulation class: Class B;
Type: EC external rotor, backward-curved centrifugal, permanent magnet brushless variable frequency
Voltage: AC110/230V (50/60Hz)
Power: 150W
Speed: 1600 RPM ±10%
Airflow: 2500m³/h±10%
Static Pressure: Medium Pressure Type 540
Noise level: 76 dB;
Control: 1–10V / PWM / speed signal output;
Protection: Stall protection, current limiting protection, soft start;
Material: Aluminum alloy fan blades + metal casing
Applications: Boilers, fresh air purification, FFU (Fan Filter Unit), air conditioning units, cabinet air conditioners, industrial ventilation
Operating temperature: -25~60+
