Product Description
SUNON MF80251V1-1000U-A99 FAN AXIAL 80X25MM 12VDC WIRE
SUNON MF80251V1-1000U-A99 FAN AXIAL 80X25MM 12VDC 2 WIRE
2026-10-30
DC Fans
SUNON MF80251V1-1000U-A99 FAN AXIAL 80X25MM 12VDC WIRE
USD$5.50
Sample Price
USD$4.50
500+ Pieces
Product Specifications
| Brand Name | SUNON |
|---|---|
| Model | MF80251V1-1000U-A99 |
| Fan Type | DC Axial Flow Cooling Fan |
| Size (mm) | 80*25mm |
| Width (mm) | 25mm |
| Bearing Type | Vapo-Bearing™ |
| Voltage (V) | 12V |
| Power (W) | 1.44W |
| Speed (RPM) | 3200RPM |
| Airflow (CFM) | 41CFM |
| Static pressure (mmH2O) | 0.180 in H2O (44.8 Pa) |
| Noise (dB) | 33dba |
| Weight (kg) | 75g |
| Operating temperature (°C) | 14 ~ 158°F (-10 ~ 70°C) |
| Certification | cURus, TUV |
SUNON MF80251V1-1000U-A99 Replace with the same parameters (80*25mm)
| Image | Brand Name | Model | Size (mm) | Width (mm) | Voltage | Current | Power | Speed | Airflow | Noise | Price |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
LD/Custom | LDDC802512VB | 80*25mm | 25mm | 12/24V/48V | 0.05-0.5A | 1.2~6.7W | 2400~5200RPM | 34~75CFM | 26~47db | $1.00 |
